Auto Industry Solutions

Nowadays, when people drive a car, they will find a lot of things such as fuel consumption display, ABS, ASR, EBA, ESP, airbag, air purifier, temperature and humidity control in the car, CD/DVD player, GPS navigation Instrumentation, electric doors and windows, electric rearview mirrors, electric seat memory adjustment, LED lights, adaptive cruise, and electronic products currently account for 23%-30% of the total vehicle cost, accounting for high-end luxury cars To 50%-60%. In the future, the development of automobiles will be driven by automobile electronic technology, and people may feel like they are operating a complex electronic device when driving a car.

Poor heat dissipation design will seriously endanger the reliability, safety, and durability of electronic products, and will also generate undesirable noise and vibration during driving, which will affect the car manufacturer’s product warranty Maintenance and car quality satisfaction and other issues. Haixinghe adopts the best NMB bearings, combines the characteristics of high safety, high reliability, and high performance products, and has passed FCC, CCC, CE and other certifications to meet customer high-quality requirements.

97×97×33MM
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
HBB9712UZ	-A	Ball	12	5.0	1.35	16.20	5000	0.63	22.12	23.03	0.91	54.3
HBB9712HZ	-A			5.0	1.10	13.20	4000	0.52	18.41	15.31	0.60	49.7
HBB9712MZ	-A			5.0	0.90	10.80	3600	0.46	16.30	11.65	0.46	47.0
HBB9712LZ	-A			5.0	0.60	7.20	3200	0.42	14.73	8.99	0.35	43.9
HBB9724UZ	-A	Ball	24	12.0	0.85	20.40	5000	0.63	22.12	23.03	0.91	54.3
HBB9724HZ	-A			12.0	0.60	14.40	4000	0.52	18.41	15.31	0.60	49.7
HBB9724MZ	-A			12.0	0.45	10.80	3600	0.46	16.30	11.65	0.46	47.0
HBB9724LZ	-A			12.0	0.30	7.20	3200	0.42	14.73	8.99	0.35	43.9

120×120×32MM
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M³/min	CFM	mmH₂O	INH₂O	dBA
HBS1212HY	-A	Sleeve	12	5.0	1.10	13.20	2800	0.66	23.36	17.29	0.68	48.5
HBS1212MY	-A			5.0	0.85	10.20	2500	0.62	22.05	15.94	0.63	45.9
HBS1212LY	-A			5.0	0.45	5.40	2100	0.42	14.90	10.32	0.41	41.1
HBB1212UY	-A	Ball		5.0	1.40	16.80	3100	0.76	26.91	20.94	0.82	51.2
HBB1212HY	-A			5.0	1.10	13.20	2800	0.66	23.36	17.29	0.68	48.5
HBB1212MY	-A			5.0	0.85	10.20	2500	0.62	22.05	15.94	0.63	45.9
HBB1212LY	-A			5.0	0.45	5.40	2100	0.42	14.90	10.32	0.41	41.1
HBS1224HY	-A	Sleeve	24	12.0	0.55	13.20	2800	0.66	23.36	17.29	0.68	48.5
HBS1224MY	-A			12.0	0.45	10.80	2500	0.62	22.05	15.94	0.63	45.9
HBS1224LY	-A			12.0	0.30	7.20	2100	0.42	14.90	10.32	0.41	41.1
HBB1224UY	-A	Ball		12.0	0.72	17.28	3100	0.76	26.91	20.94	0.82	51.2
HBB1224HY	-A			12.0	0.55	13.20	2800	0.66	23.36	17.29	0.68	48.5
HBB1224MY	-A			12.0	0.45	10.80	2500	0.62	22.05	15.94	0.63	45.9
HBB1224LY	-A			12.0	0.30	7.20	2100	0.42	14.90	10.32	0.41	41.1
HBS1248HY	-A	Sleeve	48	24.0	0.35	16.80	2800	0.66	23.36	17.29	0.68	48.5
HBS1248MY	-A			24.0	0.24	11.52	2500	0.62	22.05	15.94	0.63	45.9
HBS1248LY	-A			24.0	0.18	8.64	2100	0.42	14.90	10.32	0.41	41.1
HBB1248HY	-A	Ball		24.0	0.35	16.80	2800	0.66	23.36	17.29	0.68	48.5
HBB1248MY	-A			24.0	0.24	11.52	2500	0.62	22.05	15.94	0.63	45.9
HBB1248LY	-A			24.0	0.18	8.64	2100	0.42	14.90	10.32	0.41	41.1

120×120×25MM
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Model		Bearing	Rated Voltage	Startup Voltage	Current	Power	Speed	Air Flow		Static Pressure		Noise
Part NO.	Function	System	VDC	VDC	A	W	RPM	M³/min	CFM	mmH₂O	INH₂O	dBA
HDH1212HA	-A	Hydraulic	12	5.0	0.32	3.84	2300	2.19	77.30	3.25	0.13	39.0
HDH1212MA				5.0	0.24	2.88	2000	1.73	61.09	2.14	0.08	35.5
HDH1212LA				5.0	0.18	2.16	1700	1.62	57.31	1.60	0.06	32.7
HDB1212UA	-A	Ball		5.0	0.42	5.04	2800	2.73	96.51	4.70	0.19	44.4
HDB1212HA	-A			5.0	0.32	3.84	2300	2.19	77.30	3.25	0.13	39.0
HDB1212MA				5.0	0.24	2.88	2000	1.73	61.09	2.14	0.08	35.5
HDB1212LA				5.0	0.18	2.16	1700	1.62	57.31	1.60	0.06	32.7
HDH1224HA		Hydraulic	24	12.0	0.20	4.80	2300	2.19	77.30	3.25	0.13	39.0
HDH1224MA				12.0	0.15	3.60	2000	1.73	61.09	2.14	0.08	35.5
HDH1224LA				12.0	0.12	2.88	1700	1.62	57.31	1.60	0.06	32.7
HDB1224UA	-A	Ball		12.0	0.30	7.20	2800	2.73	96.51	4.70	0.19	44.4
HDB1224HA				12.0	0.20	4.80	2300	2.19	77.30	3.25	0.13	39.0
HDB1224MA				12.0	0.15	3.60	2000	1.73	61.09	2.14	0.08	35.5
HDB1224LA				12.0	0.12	2.88	1700	1.62	57.31	1.60	0.06	32.7
